Rotary Tube Pro 3 Hypertherm – CAM Software

• Plasma – high definition
• Plasma – conventional
• Laser
• Oxyfuel
• Waterjet

• Bevel machine*

*Requires optional module

• All major brands/manufacturers/models
• Stand-alone units and cutting table add-ons

• Report containing detailed job information and 3D part graphics
• Export report directly to PDF

• True Hole^® technology capable
• Automated job set up on the EDGE^® CNCs
• Material type, thickness and class-based process parameters:
  • Separations for cutout and pierce spacing
  • Kerf compensation and feedrate
  • Lead-in/out
  • Cutting techniques
• Cut sequencing – automatic or manual
• Automatic tabbing / micro-joints
• Ability to cut without rotation

• Create round or rectangular tube parts with parametric input
• Standard tube sizes and schedule pipe parameters (including wall thickness, corner radius, etc.) are provided for common materials, or input your own custom sizes
• 3D model of tube is updated in real time as you work, can be freely moved and rotated
  • 2D layout view is also available
• Branches can be added to define interiors using standard or custom tube sizes
  • Set branch intersection type: front outer, front inner, pass-through
  • New main tubes can be created from existing branches
• Cutouts can be added to define interiors, including layout arrays in rectangular and polar orientation
  • Select cutouts from a list of commonly used parametric shapes
• Support for a variety of end cuts
  • Straight
  • Miter
  • Pipe intersection
• Edit lead-in/out position and properties
• Control cut direction and cut sequencing on a part-by-part basis

• User-defined machine and labor production costing
• Automatic calculation of part production costs and part/nest utilization

• True shape or rectangular

• Included as standard, cut two or more parts that share a common edge

• Import DXF files to use as cutouts, allowing interiors of virtually any shape
• Import DXF text for cutting
• STEP file import for 3D CAD

• Advanced post-processor, for perpendicular cutting, with NC output
• Scribe support
• DXF output
